LWT Halo Shield Ultraviolet (UV) Water Purifier
Increments of 1
Minimum of 1
Maximum of
Sale price
$986.36 USD
-100%
Regular price
Regular price
$986.36 USD
Unit price
per
LWT Halo Shield Ultraviolet (UV) Water Purifier
Sale price
$986.36 USD
Regular price
Regular price
$986.36 USD
Unit price
per
Product Details
The Halo Shield UV Water Purifier offers advanced protection for your home. It utilizes high-intensity ultraviolet technology to neutralize 99.9% of harmful microorganisms without the use of chemicals. Built to last and engineered for efficiency, the Halo Shield delivers exceptional water purification across three flow rate models: 9 GPM, 16 GPM, and 30 GPM.
Choose the Right Model for Your Needs
- 9 GPM: For smaller households or lower water demands.
- 16 GPM: Perfect for medium-sized households or businesses.
- 30 GPM: Ideal for larger homes or applications with higher water demands.
Order Today and Enjoy Cleaner, Safer Water!
Features & Benefits
- Chemical-Free Disinfection: Effectively neutralizes bacteria and viruses without altering the taste or introducing toxic by-products.
- Environmentally Friendly: Operates without the need for harmful chemicals, providing safe and sustainable water treatment.
- Durable Design: Constructed with 304 stainless steel chambers and proprietary Lancaster high-output UV lamps for reliable performance.
- Easy Maintenance: Visual indicators, audible alarms, and reminders ensure timely lamp replacements for optimal efficiency.
Applications
The Halo Shield is ideal for homes and small businesses, ensuring clean, safe water for consumption and general use. It’s perfect for:
- Residential water disinfection
- Small-scale commercial applications
- Locations with a focus on chemical-free, sustainable water treatment
Required Pre-Treatment
To ensure optimal performance, the following water quality parameters are recommended: Iron: <0.3 ppm | Hardness: <7 gpg | Turbidity: <1 NTU | Manganese: <0.05 ppm | Tannins: <0.1 ppm | UV Transmittance: >75%
What’s Included in the Halo Shield UV Water Purifier Kit?
Each system comes complete with the necessary components for installation and operation, including:
- UV Reactor Chamber – Durable 304 stainless steel housing that directs water flow for maximum UV exposure.
- UV Lamp – High-output, low-pressure lamp designed to deliver effective microbial disinfection.
- Quartz Sleeve – Protects the UV lamp from direct water exposure while allowing optimal UV transmission.
- Electronic Ballast/Controller – Regulates lamp power and includes built-in monitoring features like lamp life countdown, failure indicators, and status alerts.
- Mounting Hardware – Brackets and fasteners for secure installation.
- O-Rings & Seals – Ensures leak-free operation and maintains system integrity.
- Power Cord (5 ft.) – Plug-and-play connection for easy electrical setup.
Product Specifications
| Feature | 9 GPM | 16 GPM | 30 GPM |
|---|---|---|---|
| Flow Rate (Industry Standard 30 mJ/cm²) | 9 GPM | 16 GPM | 30 GPM |
| Flow Rate (US Public Health Standard 16 mJ/cm²) | 17 GPM | 35 GPM | 55 GPM |
| Flow Rate (NSF/EPA 40 mJ/cm²) | 7 GPM | 14 GPM | 22 GPM |
| Pipe Size | 1.0" MNPT | 1.0" MNPT | 1.5" MNPT |
| Power Consumption | 34 W | 50 W | 90 W |
| Lamp Power | 29 W | 45 W | 80 W |
| Chamber Dimensions (DxH) | 3.5" x 17.38" | 3.5" x 25.63" | 3.5" x 39.75" |
| Operating Pressure | Up to 125 PSI | Up to 125 PSI | Up to 125 PSI |
| Pressure Drop (at 30 mJ/cm²) | <1 PSI | <1 PSI | <1 PSI |
| Temperature Range | 36°F to 104°F | 36°F to 104°F | 36°F to 104°F |
| Chamber Material | 304 Stainless Steel | ||
| Lamp Type | Low Pressure High Output (LPHO) | ||
| Lamp Life | 9,000 hours (1 year) | 9,000 hours (1 year) | 9,000 hours (1 year) |
| Monitoring Features | Lamp-on indicator, lamp life countdown (visual display), lamp replacement reminder, fault alarms, and ballast monitoring. | ||
| Electrical Requirements | 110 V to 240 V AC, 50/60 Hz with 5-ft power cord | ||
| Pre-Treatment Recommendations | Iron: <0.3 ppm, Hardness: <7 gpg, Turbidity: <1 NTU, Manganese: <0.05 ppm, Tannins: <0.1 ppm, UV Transmittance: >75% | ||
